Thermal conductivity 3D woven distance fabric

Name: Thermal conductivity 3D woven distance fabric
Brand: CHINA BEIHAI
Price: 20.00 USD

Wholesale Thermal conductivity 3D woven distance fabric from china suppliers

Place of Origin : Jiangxi, China

Brand Name : CHINA BEIHAI

Model Number : BH-3D

Application : Wall/Roof covering Cloth, Bulkhead,boat,ribs,wind power,grp tank

Weight : 780-2000g/m2

Surface Treatment : Silicon Coated

Width : 1270mm

Weave Type : Plain Woven

Yarn Type : E-glass

Alkali Content : Alkali Free

Standing Temperature : 260

Processing Service : Cutting

Name : Thermal conductivity 3D woven distance fabric

Color : White

Thickness : 2mm-60mm

Good Features : Moisture Resistance,sound insulation,impact resistant,heat insulation

Type : 3D Fiberglass Fabric

Material : Glassfiber

Keyword : Glass Fiber Fabric

Usage : Thermal Protective Fabric,building application

Item : 3D fiberglass fabric

Packaging Details : Thermal conductivity 3D woven distance fabric was put into carton

Port : Shanghai

Supply Ability : 5000 Square Meter/Square Meters per Week Thermal conductivity 3D woven distance fabric

MOQ : 100 Square Meters

Price : $20.00/Square Meters >=100 Square Meters

Contact Now

Thermal conductivity 3D woven distance fabric

Products Description

3-D spacer fabric construction is a newly developed concept. The fabric surfaces are strongly connected to each other by the vertical pile fibers which are interwoven with the skins. Therefore, the 3-D spacer fabric can provide good skin-core debonding resistance, excellent durability and superior integrity. In addition, the interstitial space of the construction can be filled up with foams to provide synergistic support with vertical piles.

3D Fiberglass including 3D Fiberglass Woven Fabric, 3D fabric composited sandwich Panels

Get Sample & Quotation

PRODUCT SPECIFICATIONS

Area Weight (g/m2)	Core Thickness (mm)	Density of Warp (ends/cm)	Density of Weft (ends/cm)	Tensile strength Warp (n/50mm)	Tensile strength Weft (n/50mm)
740	2	18	12	4500	7600
800	4	18	10	4800	8400
900	6	15	10	5500	9400
1050	8	15	8	6000	10000
1480	10	15	8	6800	12000
1550	12	15	7	7200	12000
1650	15	12	6	7200	13000
1800	18	12	5	7400	13000
2000	20	9	4	7800	14000
2200	25	9	4	8200	15000
2350	30	9	4	8300	16000

Company Profile

Quality Assurance

Product packaging

Application

The products have broad application prospects in automobile, Locomotives, aerospace, marine, windmills, building and other industries.
